N-type Technology N-type modules with Tunnel Oxide Passivating Contacts (TOPcon) technology offer lower LID/LETID degradation and better low light performance. HOT 3.0 Technology N-type modules with JinkoSolar’s HOT 3.0 technology offer better reliability and efficiency. Durability Against Extreme Environment High salt fog and ammonia resistance. Mechanical Load Enhanced Certified to withstand: 5400 Pa front side max static test load 2400 Pa rear side max static test load SMBB Technology Better light trapping and current collection to improve module power output and reliability. Anti-PID guarantee Minimizes the chance of degradation caused by PID phenomena through optimization of cell production technology and material control.
Jinko JKM600N-72HL4-V 580-605 1500V Silver Frame
Out of stock
| Module Power | 600 W |
| Cell Type | N-Type |
| Colour Frame | Silver Frame |
| Module type | Monofacial |
| Series Name | JKM580-605N-72HL4-(V)-F8-EN |
| Series Power Range (Wp) | 580-605 |
| Model Name | JKM585N-72HL4-V |
| Warranty Years | 12 |
| Primary (Years, % Output Power) | 30, 87.4 |
| Voltage at Maximum Power, Vmpp (V) At STC | 43.53 |
| Current at Maximum Power, Impp (A) At STC | 13.44 |
| Open Circuit Voltage, Voc (V) At STC | 52.47 |
| Short Circuit Current, Isc (A) At STC | 14.07 |
| Panel Efficiency (%) At STC | 22.65 |
| Temperature coefficient of Pmax (%/°C). | -0.29 |
| Temperature coefficient of Voc (%/°C) | -0.25 |
| Temperature coefficient of Isc (%/°C) | 0.045 |
| Maximum System Voltage (V) | 1500 |
| Series Fuse Rating (A) | 25 |
| Cell Number | 144 |
| Glass Type | Anti-reflection Coating, High Transmission, Low Iron, Tempered Glass |
| Glass Thickness (mm) | 3.2 |
| Frame Type | Anodized Aluminum Alloy |
| Junction Box Protection Class | IP68 |
| Connector Type | JK03M/MC4/Others |
| Cable Crosssection (mm²) | 4 |
| Cable Length (mm) | (+):400 mm ,(-):200 mm or Customized Length |
